2012 Ford Econoline Wagon XL



Visit our Store

Vehicle Information

VIN: 1FBNE3BL5CDB00029
Stock #: 0118517B
Model Code: E3B
  • Body Style Full-size Passenger Van
  • Mileage 270,000
  • Engine 8 Cyl - 5.4 L
  • Transmission Automatic
  • Fuel Type Gasoline

All Features

  • Spare tire and wheel
  • 120 amp alternator
  • Electronic throttle control
  • Front stabilizer bar
  • Pwr steering
  • Rear-wheel drive
  • Tire pressure monitoring system (TPMS)
  • 4-Wheel Disc Brakes
  • A/C
  • ABS
  • Adjustable Steering Wheel
  • AM/FM Stereo
  • Auxiliary Audio Input
  • Bucket Seats
  • Conventional Spare Tire
  • Driver Air Bag
  • Intermittent Wipers
  • Passenger Air Bag
  • Power Outlet
  • Power Steering
  • Rear Bench Seat
  • Rear Wheel Drive
  • Stability Control
  • Steel Wheels
  • Tire Pressure Monitor
  • Tires - Front All-Season
  • Tires - Rear All-Season
  • Traction Control
  • Vehicle
    • Rear Door Type: Dual Hinged
  • Mileage
    • Fuel Economy Est-Combined (MPG): 13
    • EPA Fuel Economy Est - City (MPG): 11
    • EPA Fuel Economy Est - Hwy (MPG): 15
  • Electrical
    • Cold Cranking Amps @ 0° F (Primary): 650
    • Maximum Alternator Capacity (amps): 120
    • Maximum Alternator Watts: 1620
  • Cooling System
    • Total Cooling System Capacity (qts): 25.9
  • Weight Information
    • Gross Axle Wt Rating - Front (lbs): 3700
    • Gross Axle Wt Rating - Rear (lbs): 6084
    • Curb Weight - Front (lbs): 3059
    • Curb Weight - Rear (lbs): 2969
    • Gross Vehicle Weight Rating Cap (lbs): 9500
    • Gross Combined Wt Rating (lbs): 13000
  • Trailering
    • Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
    • Dead Weight Hitch - Max Tongue Wt. (lbs): 500
    • Wt Distributing Hitch - Max Trailer Wt. (lbs): 6700
    • Wt Distributing Hitch - Max Tongue Wt. (lbs): 1005
  • Suspension
    • Suspension Type - Front: Independent
    • Suspension Type - Rear: Live Axle
    • Spring Capacity - Front (lbs): 3400
    • Spring Capacity - Rear (lbs): 5545
    • Axle Type - Front: Twin I-Beam
    • Axle Type - Rear: Semi-Floating
    • Axle Capacity - Front (lbs): 5000
    • Axle Capacity - Rear (lbs): 6340
    • Axle Ratio (:1) - Rear: 3.73
    • Shock Absorber Diameter - Front (mm): 35.0
    • Shock Absorber Diameter - Rear (mm): 35.0
    • Stabilizer Bar Diameter - Front (in): 1.0
  • Brakes
    • Brake Type: Pwr
    • Brake ABS System: Four Wheel
    • Disc - Front (Yes or ): Yes
    • Disc - Rear (Yes or ): Yes
    • Front Brake Rotor Diam x Thickness (in): 13.6 x 0.5
    • Rear Brake Rotor Diam x Thickness (in): 13.6 x 0.4
  • Tires
    • Front Tire Order Code: T37
    • Rear Tire Order Code: T37
    • Front Tire Size: LT225/75R16E
    • Rear Tire Size: LT225/75R16E
    • Spare Tire Size: LT225/75R16E
    • Front Tire Capacity (lbs): 2680
    • Rear Tire Capacity (lbs): 2680
    • Spare Tire Capacity (lbs): 2680
    • Revolutions/Mile @ 45 mph - Front: - TBD -
    • Revolutions/Mile @ 45 mph - Rear: - TBD -
    • Revolutions/Mile @ 45 mph - Spare: - TBD -
  • Wheels
    • Front Wheel Size (in): 16 x 7.0
    • Rear Wheel Size (in): 16 x 7.0
    • Spare Wheel Size (in): 16 X 7.0
    • Front Wheel Material: Steel
    • Rear Wheel Material: Steel
    • Spare Wheel Material: Steel
  • Steering
    • Steering Type: Pwr Recirculating Ball
    • Steering Ratio (:1), On Center: 17.0
    • Steering Ratio (:1), At Lock: 17.0
    • Turning Diameter - Curb to Curb (ft): 48.6
    • Turning Diameter - Wall to Wall (ft): 50.0
  • Frame
    • Frame Type: Single-Channel
  • Fuel Tank
    • Fuel Tank Capacity, Approx (gal): 33.0
    • Fuel Tank Location: Midship
  • Doors
    • Side Door Type: Hinged 60/40
  • Exterior Dimensions
    • Wheelbase (in): 138.0
    • Length, Overall w/rear bumper (in): 216.7
    • Width, Max w/o mirrors (in): 79.4
    • Height, Overall (in): 83.1
    • Overhang, Front (in): 34.9
    • Overhang, Rear w/bumper (in): 43.8
    • Ground to Top of Load Floor (in): 30.2
    • Ground Clearance, Front (in): - TBD -
    • Ground Clearance, Rear (in): - TBD -
    • Rear Door Opening Height (in): 46.8
    • Rear Door Opening Width (in): 54.4
    • Side Door Opening Height (in): 47.2
    • Side Door Opening Width (in): 44.8
    • Step Up Height - Front (in): - TBD -
    • Step Up Height - Side (in): - TBD -
  • Cargo Area Dimensions
    • Cargo Area Length @ Floor to Console (in): 138.7
    • Cargo Area Length @ Floor to Seat 1 (in): 120.6
    • Cargo Area Length @ Floor to Seat 2 (in): 84.9
    • Cargo Area Length @ Floor to Seat 3 (in): 51.4
    • Cargo Area Length @ Floor to Seat 4 (in): 20.8
    • Cargo Area Width @ Beltline (in): - TBD -
    • Cargo Box Width @ Wheelhousings (in): 51.1
    • Cargo Box (Area) Height (in): 51.9
    • Cargo Volume to Seat 1 (ft³): 237.8
    • Cargo Volume to Seat 2 (ft³): - TBD -
    • Cargo Volume to Seat 3 (ft³): - TBD -
    • Cargo Volume to Seat 4 (ft³): - TBD -
  • Interior Dimensions
    • Passenger Capacity: 12
    • Front Head Room (in): 42.0
    • Front Leg Room (in): 40.0
    • Front Shoulder Room (in): 68.1
    • Front Hip Room (in): 65.6
    • Second Head Room (in): 40.2
    • Second Leg Room (in): 38.8
    • Second Shoulder Room (in): 71.7
    • Second Hip Room (in): 66.5
    • Third Head Room (in): 40.1
    • Third Leg Room (in): 40.0
    • Third Shoulder Room (in): 71.7
    • Third Hip Room (in): 66.8
    • Fourth Head Room (in): 38.9
    • Fourth Leg Room (in): 39.4
    • Fourth Shoulder Room (in): 69.4
    • Fourth Hip Room (in): 66.1
  • Summary
    • Vehicle Name: Ford Econoline Wagon
    • Body Style: Passenger Van
    • Body Code: 138.0" WB
  • Emissions
    • EPA Greenhouse Gas Score: 1
    • Tons/yr of CO2 Emissions @ 15K mi/year: 14.1
